SRS Power SKID Solutions
SRS Power SKID Solutions provide a fully integrated, factory prefabricated system that consolidates the LV Main Switchboard, UPS Input Board, UPS Output Board, UPS units and an optional Isolation Transformer into a single compact modular unit. Engineered to minimize on site coordination, shorten installation time and ensure consistent quality through complete prefabrication and thorough pre-delivery factory testing, this solution maximizes space efficiency and performance for modern data centers and other mission critical facilities.
< LV Switchgear
SRS Power SKID Solutions

Product Description
SRS Power SKID Solutions provide a fully integrated, factory prefabricated system that consolidates the LV Main Switchboard, UPS Input Board, UPS Output Board, UPS units and an optional Isolation Transformer into a single compact modular unit. Engineered to minimize on site coordination, shorten installation time and ensure consistent quality through complete prefabrication and thorough pre-delivery factory testing, this solution maximizes space efficiency and performance for modern data centers and other mission critical facilities.
General Specification
- Standard: IEC 60439-1 & -2, IEC 61641
- Standard: IEC 60529, IEC 61000-6-2 & -4
- Standard: IEC 62040
- Rated Voltage: Up to 440V
- Rated Current: Up to 6300A
- Rated Frequency: 50Hz
- Rated Short Time Withstand Current: Up to 100kA, 3 Sec
- Rated Impulse Voltage Withstand: 8kV
- Form of Segregation: Up to Form 4B
- Degree of Protection (Indoor): Up to IP43
- Cable/ Busduct Entry: Top
- Enclosure Type: Floor Standing
- Accessibility: Front/ Back
General Specification
- Standard: IEC 60439-1 & -2, IEC 61641
- Standard: IEC 60529, IEC 61000-6-2 & -4
- Standard: IEC 62040
- Rated Voltage: Up to 440V
- Rated Current: Up to 6300A
- Rated Frequency: 50Hz
- Rated Short Time Withstand Current: Up to 100kA, 3 Sec
- Rated Impulse Voltage Withstand: 8kV
- Form of Segregation: Up to Form 4B
- Degree of Protection (Indoor): Up to IP 43
- Cable/ Busduct Entry: Top
- Enclosure Type: Floor Standing
- Accessibility: Front/ Back
